TUBE (copper)
| mm/inch | 7,00 | |
| THICKNESS (mm) | SMOOTH | 0.25 - 0.26 - 0.27* |
| GROOVED | 0.37** | |
| *on request **peak thickness | ||
FINS
| MATERIALS | aluminium/prepain. alum. hydrophile aluminium/copper |
| THICKNESS mm | FINS SPACING |
| 0.10 | 1.8 - 3.00 MAX |
| 0.15 | 3.2 - 4.2 |
| FIN EDGE | STRAIGHT - SINE WAVE RIPPELED EDGE |
| FINS' SHAPE | CORRUGATED LOUVERED |
FRAME
| MATERIALS | THICKNESS mm |
| GALVANIZED STEEL | 1.0 - 1.2 - 1.5 - 2.0 |
| ALUMINIUM | 1.0 - 1.2 - 1.5 - 2.0 |
| PERALUMAN | 1.2 - 1.5 - 2.0 |
| STAINLESS STEEL | 1.0 - 1.2 - 1.5 |
| BRASS | 1.2 - 1.5 |
| COPPER | 1.5 - 2.0 |
CONVEYORS
| Ø INT. NOZZLE mm | 240 ÷ 585 |
